ZigBee 3.0 Signal Repeater USB Signal Amplifier Extender

ZigBee 3.0 USB Signal Repeater & Range Extender for Smart Home Automation (Compatible with eWeLink App & ZigBee Gateways)

Product Overview:

Boost the performance of your smart home or office automation system with this compact ZigBee 3.0 USB Signal Repeater. Designed to extend the range and reliability of your ZigBee network, this device ensures stable communication between your ZigBee hub and connected devices—even across larger spaces or through signal-blocking walls.

Key Features:

Reliable Signal Extension: Expands ZigBee signal coverage up to 20–50 meters, helping eliminate dead zones and ensuring consistent device control throughout your space.

Compact & Cost-Effective: The mini USB design makes it easy to plug into any USB power source, offering a low-cost solution to extend your ZigBee network without needing additional hubs.

Seamless Integration: Works with the eWeLink app and is compatible with ZigBee gateways like Z2M (Zigbee2MQTT). Simply add the repeater to your app and plug it into a wall adapter or USB port.

One Hub Required: This device acts as a signal relay, not a standalone hub. Ensure you have an existing ZigBee hub before use.

Technical Specifications:

• Power Input: 5V 1A (via USB)
• Operating Voltage: 1.8V–3.8V
• Transmit Power: +21dBm
• Frequency Range: 2.400–2.483 GHz
• Wireless Protocol: ZigBee 3.0
• Operating Temperature: -10℃ to 55℃
• Humidity Tolerance: 0–90% RH (non-condensing)
• Dimensions: 50.5 × 24 × 8 mm
• App Compatibility: eWeLink

Ideal For:

• Expanding ZigBee coverage in large homes or offices
• Improving connectivity in areas with thick walls or interference
• Enhancing the reliability of smart lighting, sensors, switches, and other ZigBee devices
